SPECIFICATION:
DC Voltage Measurement:
400mV +/- (0.8%+3)
4V / 40V / 400V +/- (0.5%+1)
1000V +/- (1.0%+3)
AC Voltage Measurement:
400mV +/- (1.2%+5)
4V / 40V / 400V +/- (1.2%+5)
750V +/- (1.2%+5)
DC Current Measurement:
400µA / 4000µA +/- (1.0%+2)
40mA / 400mA +/- (1.2%+3)
4A / 10A +/- (1.5%+3)
AC Current Measurement:
400µA / 4000µA +/- (1.2%+5)
40mA / 400mA +/- (1.5%+5)
4A / 10A +/- (2.0%+5)
Resistance Measurement:
400 Ohm +/- (1.2%+2)
4 kOhm / 40 kOhm / 400 kOhm +/- (1.0%+2)
4 MOhm +/- (1.2%+2)
40 MOhm +/- (1.5%+2)
Capacitance Measurement:
40nF +/- (3.0%+5)
400nF / 4µF / 40µF +/- (3.0%+5)
400µF +/- (4.0%+5)
4000µF: only reference
Frequency: 10Hz~10MHz +/- (0.1%+4)
Frequency Response: 45 ~ 400Hz
Duty Cycle: 0.1% ~ 99.9%
SPECIAL FUNCTIONS:
Manual Ranging
Diode
EF Function
Audion 1000ß
Continuity Buzzer
Data Hold
Max/Min Mode
Display Backlight
REL
Analogue Bar Graph 41
Fuse
Input Impedance for DC Voltage Measurement Around 10 MOhm
Low Battery Display < 7.5V
GENERAL CHARACTERISTICS:
Power: 9V battery (6F22) x 1
LCD Size: 65 x 43mm
Product Net Weight: 370g
Product Size: 180 x 87 x 47mmh Manual
