G5Q-1A4-EU 24VDC

Relay, SPST-NO, 24V DC, 10A / 250V AC, 5A / 30V DC

Manufacturer partno	G5Q-1A4-EU 24VDC
RoHS	yes
Manufacturer	OMRON OCB
Mounting	PCB
Terminal pitch	2.54mm, 2,54mm
Operating temperature	-40...85°C
Body dimensions	20.3x10.3x15.8mm
Body dimensions	20.3x10.3x15.8mm
Contacts configuration	SPST-NO
Type of relay	electromagnetic
Rated coil voltage	24V DC
Contact current max.	10A
Switched voltage	max. 277V AC, max. 30V DC
Relay variant	miniature
Coil resistance	2.88kΩ
Operate time	10ms
Release time	5ms
Coil power consumption	200mW
Relay series	G5Q-EU
Contact resistance	100mΩ
Coil current	8.3mA
Enclosure description	hermetic seal
DC contacts rating @R	5A / 30V DC
AC contacts rating @R	10A / 250V AC

Extended distributor/manufacturer information (EU Regulation 2023/988)

Trade name: HESTORE Hungary Ltd
Postal address: Cziraki street 26-32, Budapest, H1163
Electronic address: https://www.hestore.hu/

Part.No: 100.471.11

Add to favorites

Quantity (pcs):

Unit price excl. VAT

1+	1 917 Ft
5+	1 679 Ft
10+	1 630 Ft
20+	1 591 Ft
50+	1 543 Ft
