P3705

RC bridge, resistance and capacity measurement, 3.5 digit LCD display

Manufacturer partno	P 3705
Manufacturer	PEAKTECH
Dimensions	85x175x40mm
Power supply	battery 6LR61 9V x1
Type of meter	CR meter
Measuring instrument features	socket for testing transistors' gain (hFE) parameter
Resistance measuring range	200kΩ, 20Ω, 200Ω, 2kΩ, 20kΩ, 2MΩ, 20MΩ, 200MΩ, 2GΩ
Resistance measuring accuracy	±(0.8%+1 digit)
Capacitance measuring range	20µF, 2µF, 200µF, 2nF, 20nF, 2mF, 20mF, 200pF, 200nF
Capacitance measuring accuracy	±(0.5%+ 10 digit)
Diode test	1mA @2.8V
Continuity test	acoustic indication, <120Ω
Standard equipment	test leads, user's manual
Kind of display used	LCD
Measurement	resistance, capacitance, continuity
Battery/ rechargeable battery	battery 6LR61 9V x1
