C091-T3402-000

Name: C091-T3402-000
Brand: AMPHENOL
SKU: 100.337.85
Availability: InStock

C091A kerek aljzat, 6 pol.

Érintkező bevonata ezüstözött
Pinek száma 6
Blokkolás fajtája csavarral, külső menet
Szigetelési osztály IP40
Elektromos szerelés forrasztás
Mechanikai szerelés panelre, anyacsavar hátulról
Névleges feszültség 300V
Üzemi hőmérséklet -40...100°C
Névleges áram 5A
Szabvány megfelelőség UL E63093
Csatlakozó kieveztésrendszer DIN EN 60130-9
Panelvastagság max 3.5mm

RoHS	no
Manufacturer	AMPHENOL
Connector	socket
Connector variant	M16
Kind of connector	male
Number of pins	6
Electrical mounting	soldering
Mechanical mounting	for panel mounting, rear side nut
Rated voltage	300V
Current rating	5A
Contact plating	silver plated
IP rating	IP40
Connector series	C091A
Locking system	screwed, external thread
Wire cross section	0.5mm²
Panel thickness	max 3.5mm
Kind of connector	male

Extended distributor/manufacturer information (EU Regulation 2023/988)

Trade name: HESTORE Hungary Ltd
Postal address: Cziraki street 26-32, Budapest, H1163
Electronic address: https://www.hestore.hu/

Part.No: 100.337.85

Add to favorites

Quantity (pcs):

Unit price excl. VAT

1+	2 419 Ft
5+	2 160 Ft
10+	2 103 Ft
20+	2 056 Ft
50+	1 996 Ft

* The prices according to your settings are displayed without VAT, that contains your custom discount if available, without shipping costs. For modify please click

icon on top menu.

Availability	Qu.
In stock	> 1
3 workdays	> 5
