RM85-P-24VAC

Relay, SPDT, 24V AC, 16A / 250V AC, 16A / 24V DC, 16A

Manufacturer partno	RM85-2011-35-5024
RoHS	yes
Manufacturer	RELPOL
Mounting	PCB
Terminal pitch	5mm
Operating temperature	-40...85°C
Body dimensions	29x12.7x15.7mm
Body colour	white
Related items	GD50, GZ80, GZM80, GZM80-BK, GZT80, PW80
Current rating	16A
IP rating	IP67
Contact material	AgNi
Contacts configuration	SPDT
Type of relay	electromagnetic
Rated coil voltage	24V AC
Contact current max.	16A
Switched voltage	max. 440V AC, max. 250V DC
Relay variant	miniature, miniature
Coil resistance	400Ω
Coil voltage min.	19.2V AC
Coil voltage max.	28.8V AC
Coil power consumption	750mVA
Relay series	RM85
Contact resistance	100mΩ
DC contacts rating @R	16A / 24V DC
AC contacts rating @R	16A / 250V AC
OEM number	604651

Extended distributor/manufacturer information (EU Regulation 2023/988)

Trade name: HESTORE Hungary Ltd
Postal address: Cziraki street 26-32, Budapest, H1163
Electronic address: https://www.hestore.hu/

Part.No: 100.324.57

Add to favorites

Quantity (pcs):

Unit price gross (netto)

1+	£ 2.445 (£ 1.925 +VAT)
5+	£ 1.960 (£ 1.543 +VAT)
10+	£ 1.873 (£ 1.475 +VAT)
20+	£ 1.814 (£ 1.429 +VAT)
50+	£ 1.751 (£ 1.378 +VAT)

The price includes 27% VAT.

* The price according to your settings are displayed including VAT, that contains your custom discount if available, without shipping costs. For modify please click

icon on top menu.

Availability	Qu.
In stock	> 5
3 workdays	> 2000
