HX-4S-A01

Name: HX-4S-A01
Brand: HESTORE
SKU: 100.468.35
Availability: InStock

BMS module, 4S, 16.8V, 8A

One of the main disadvantages of lithium batteries is that they are very sensitive to the parameters of charging and discharging, especially overcharging and deep discharging.
Therefore, if we want to build a long-lasting, high-capacity energy storage, additional electronics may be necessary.
Collectively, these electronic devices are called Battery Management System or BMS.

Attention! BMS modules do not replace charging circuits! The charging current is not regulated!

Operating temperature	-40...50°C
Protection	Over current, Over-discharge, Overcharging, Short circuit
Operating current	8A
Dimensions	72 x 17.7 x 3mm
Max. forward impulse current	12A
Supply current	30μA
Cells quantity	4
Type of rechargeable battery	Li-Ion/Polymer
Overcharge threshold	4.25...4.35 ±0.05V
Over-discharge voltage threshold	2.5...3.0V ±0.05V
Cell balancing	none
Charging voltage	16.8V
Battery contacts	nickel plated, suitable for spot welding

Extended distributor/manufacturer information (EU Regulation 2023/988)

Trade name: HESTORE Hungary Ltd
Postal address: Cziraki street 26-32, Budapest, H1163
Electronic address: https://www.hestore.hu/

Part.No: 100.468.35

Add to favorites

Quantity (pcs):

Unit price excl. VAT

1+	1 572 Ft
5+	1 381 Ft
10+	1 339 Ft
20+	1 306 Ft
50+	1 266 Ft

* The prices according to your settings are displayed without VAT, that contains your custom discount if available, without shipping costs. For modify please click

icon on top menu.

Availability	Qu.
In stock	> 5
10-15 workdays	> 2000
