POM1615 LIN 1M B
Potentiometer, 6mm shaft, 1MΩ, mono, linear
| RoHS | yes |
|---|---|
| Case | POM1615 |
| Power | 125mW |
| Resistance | 1MΩ |
| Characteristics | linear |
| Series | POM1615 |
| Lanes | mono |
| Mounting | THT |
| Tolerance | ±20% |
| Terminal pitch | 5mm |
| Body dimensions | Ø17 x 9.2mm, Ø17x9.2mm |
| Max. operating voltage | 200V |
| Leads | for PCB |
| Type of potentiometer | shaft |
| Track material | carbon |
| Shaft diameter | 6mm |
| Shaft surface | knurled |
| Shaft length | 9mm |
| Thread length | 6mm |
| Mechanical rotation angle | 300° |
| Potentiometer features | mono |
| Body material | metal |
| Panel cutout diameter | 7.2mm |
| Kind of potentiometer | single turn |
| L shaft length | 15mm |
| Korpusz anyaga | metal |
Extended distributor/manufacturer information (EU Regulation 2023/988)
Trade name: HESTORE Hungary Ltd
Postal address: Cziraki street 26-32, Budapest, H1163
Electronic address: https://www.hestore.hu/
Part.No: 100.462.70
Quantity (pcs):
Unit price excl. VAT
| 1+ | 268 Ft |
|---|---|
| 5+ | 168 Ft |
| 10+ | 144 Ft |
| 20+ | 132 Ft |
| 50+ | 122 Ft |
* The prices according to your settings are displayed without VAT, that contains your custom discount if available, without shipping costs.
For modify please click
icon on top menu.
icon on top menu. | Availability | Qu. |
|---|---|
| In stock | > 25 |
| 10-15 workdays | > 10000 |
