Main category » Analog ICs » Power supply ICs »

TSR 1-24120

DC/DC Step-down module 12V, 1A

Manufacturer partno	TSR 1-24120
RoHS	yes
Manufacturer	TRACO POWER
Case	SIP3
Weight	1.9g
Output voltage	12V DC
Input voltage	15...36V
Series	TSR 1
Operating temperature	-40...85°C
Body dimensions	11.7x10.2x7.6mm
Output current	1A
Protection	overload, short-circuit
Number of outputs	1
Efficiency	95%
Type of converter	DC/DC
Switching frequency	500kHz

Extended distributor/manufacturer information (EU Regulation 2023/988)

Trade name: HESTORE Hungary Ltd
Postal address: Cziraki street 26-32, Budapest, H1163
Electronic address: https://www.hestore.hu/

Part.No: 100.407.28

Add to favorites

Quantity (pcs):

Unit price excl. VAT

1+	2 925 Ft
5+	2 645 Ft
10+	2 580 Ft
20+	2 525 Ft
50+	2 452 Ft

* The prices according to your settings are displayed without VAT, that contains your custom discount if available, without shipping costs. For modify please click

icon on top menu.

Availability	Qu.
3 workdays	> 2000
