66.82.9.012.0300

Relé, 12V DC 30A

Manufacturer partno	66.82.9.012.0300
RoHS	yes
Manufacturer	FINDER
Operating temperature	-40...70°C
Body dimensions	68.5x33.5x31mm
Leads	6,3x0,8mm connectors
Contacts configuration	DPST-NO
Type of relay	electromagnetic
Rated coil voltage	12V DC
Contact current max.	30A
Switched voltage	max. 220V DC, max. 440V AC
Relay variant	power
Coil resistance	85Ω
Coil power consumption	1.7W
Relay series	66.82
Coil current	141mA
DC contacts rating @R	30A / 30V DC
AC contacts rating @R	30A / 250V AC
