EB40202S2-000U-999
40x40x20mm, 24V DC, siklócsapágy ventilátor
| RoHS | yes |
|---|---|
| Manufacturer | SUNON |
| Type | DC |
| Voltage | 5V |
| Weight | 31g |
| Operating voltage | 12...27.6V |
| Operating temperature | -10...70°C |
| Supply voltage | 24V DC |
| Enclosure material | thermoplastic |
| Current rating | 0.033A |
| Leads | 2 leads |
| Min. insulation resistance | 500MΩ |
| IP rating | E |
| Flammability rating | UL94V-0 |
| Wire size | 26AWG |
| Cable length | 300mm |
| Type of fan | DC |
| Fan kind | shaft |
| Fan dimensions | 40x40x20mm |
| Power consumption | 0.8W |
| Fan efficiency | 13.01m3/h |
| Noise level | 21dBA |
| Bearing type | slide bearing |
| Rotational rate/speed | 6200 (±15%)rpm |
| Current and power consumption tolerance | ±15% |
| Impeller material | thermoplastic |
| Static pressure | 4.06mm H2O |
| Fan motor | brushless DC |
| Kind of fan | shaft |
| Kind of Bearing | slide bearing |
