Physical characteristics:
- Dimensions: 60mm(L)×47.98mm(W)×12mm(H)
- Weight: 20g
- Color: White

Bluetooth Interface:
- Protocol: Bluetooth Smart (Bluetooth Low Energy /Bluetooth 4.0)
- Power Source: Rechargeable Lithium-ion Battery (Charging through USB)
- Speed: 1Mbps

USB Host Interface:
- Protocol: USB Full Speed
- Type: Four Line:+5V,GND,D+ and D-
- Connector Type: Micro USB
- Power Source: From USB Port
- Speed: USB Full Speed (12 Mbps)
- Cable Length: 1 m (Datachable)
- Firmware: Upgradeable through USB Interface

Contactless Smart Card Interface
- Standard: ISO 14443 Type A,MIFARE,DESFIRE
- Protocol: ISO 14443 T=CL for ISO14443-4 compliant cards, and T+CL Emulation for MIFARE Classic 1k/4k and NFC tags
- Operating Frequency: 13.56MHz
- Operating Distance: Up to 25mm(depending on tag type)
- Smart Card Read/ Write Speed: 106Kbps,212Kbps,424Kbps
- Antenna Size: 28.00mm×32.00mm

Built-in Peripherals
- LED: 2bi-color, Red and Blue,Red and Green
- Buzzer: Monotone

Operating Conditions
- Temperature: 0...50℃
- Humidity: Max.90%(non-condensing)
- MTBF: 500,000 hrs

Application Programming Interface
- PC-link Mode: PC/SC, CT-API(through wrapper on top of PC/SC)
- Certifications/Compliance: EN60950/IEC 60950,ISO 14443,USB Full Speed,Bluetooth Smart, PC/SC,CCID,RoHS 2, REACH, Microsoft WHQL
- Device Driver Operating System Support: Windows : ME, 98, 2000, XP, Vista, 7, 8, 8.1, 10, Server2003,2008,2008R2,2012,2012R2
Linux
Mac OS
Android 4.3 +
iOS 5.0 +
