TK4M-14RN
PID temperature controller (thermostat), SSR control output, SPST-NO, 3 outputs
Only a qualified electrician allowed to install the device in a suitable switch/control cabinet.
| Manufacturer partno | TK4M-14RN |
|---|---|
| Manufacturer | AUTONICS |
| Series | TK4M |
| Mounting | for panel mounting |
| Operating temperature | -10...50°C |
| Body dimensions | 72x72x70.5mm |
| Supply voltage | 100...240V AC |
| Interface | RS485 |
| Mounting hole diameter | 68x68mm |
| Body dimensions | 72x72x70.5mm |
| Type of module | regulator |
| IP rating | IP65 |
| Kind of temperature sensor | Pt100, K hőelem, thermocouple B, thermocouple C, Cu50, Cu100, thermocouple E, thermocouple G, thermocouple J, JPt100, thermocouple L, thermocouple N, Ni120, thermocouple PLII, Pt50, thermocouple R, thermocouple S, thermocouple T, thermocouple U |
| Input 1 type | multipurpose, 4...20mA, 0...5V, 0...100mV, 0...10V, 0...20mA |
| Display height 1 | 20mm |
| Controlled parameter | temperature, hőmérsékletet |
| Controlled parameter range | -1999...9999 |
| Kind of output 1 | SPST-NO |
| The programming method | foil keypad |
| Kind of display used | LED x2 |
| Output 1 electrical parameters | 30V DC / 3A, 250V AC / 3A |
| Insulation class | for panel mounting |
| Input 1 properties | analogue voltage, RTD, thermocouple, current analog |
| Kimenet 3 fajtája | SPST-NO, alarm |
| Szabályozás az 1 kimenetnél | ON-OFF, P, PD, PI, PID |
| A 3 kimenet elektromos paraméterei | 250V AC / 3A |
| Az 1 kijelző magassága | 20mm |
| A 2-es kijelző magassága | 15mm |
Extended distributor/manufacturer information (EU Regulation 2023/988)
Trade name: HESTORE Hungary Ltd
Postal address: Cziraki street 26-32, Budapest, H1163
Electronic address: https://www.hestore.hu/
Part.No: 100.484.69
Quantity (pcs):
Unit price excl. VAT
| 1+ | 22 513 Ft |
|---|---|
| 5+ | 21 431 Ft |
| 10+ | 21 045 Ft |
| 20+ | 20 669 Ft |
| 50+ | 20 114 Ft |
* The prices according to your settings are displayed without VAT, that contains your custom discount if available, without shipping costs.
For modify please click
icon on top menu.
icon on top menu. | Availability | Qu. |
|---|---|
| 3 workdays | > 2 |
