Supply voltage: 24V DC
Power consumption: <3W
Output: 2 x Relay contact 10A/240V
Terminals: Power, Out1, Out2: 3 x 2p 5.08mm screw terminal
Display: Dual 3-digit 7-segment LED display red/blue

Sensor: 2 x NTC 10k, Ø4 x 20mm, waterproof
Sensor cable length: 2 x 1m

Temperature measurement range: -55...120°C
Accuracy: ±1°C
Resolution: 0.1°C

Material: ABS
Dimensions: 75 x 34.5 x 85mm
Installation opening size: 71 x 29mm
Installation thickness: 0...16mm

Current measured temperature 1: left display / Red
Current measured temperature 2: right display / Blue

UP arrow long pressed: set switch-on temperature (flashing)

DOWN arrow long pressed: set switch-off temperature (flashing)

By long pressing the two UP arrows together, you can set delay and alarm:
You can use UP/DOWN arrows 1 to scroll between functions
You can use UP/DOWN arrows 2 to set values

F0: Switch-on delay 1 (0...60min)
F1: Switch-on delay 2 (0...60min)
F2: High temperature alarm (-55...120°C)
F2: Low temperature alarm (-55...120°C)

After a short period of inactivity, the set values ​​are saved and the system returns to the default state.
