G6B-1114P-US-12VDC

Relay, SPST-NO, 12V DC, 5A / 250V AC, 5A / 30V DC

Manufacturer partno	G6B-1114P-US 12VDC
RoHS	yes
Manufacturer	OMRON OCB
Mounting	socket, PCB, socket
Terminal pitch	7.62mm
Operating temperature	-25...70°C
Body dimensions	20x10x10mm
Body dimensions	20x10x10mm
Contacts configuration	SPST-NO
Type of relay	electromagnetic
Rated coil voltage	12V DC
Contact current max.	5A
Switched voltage	max. 125V DC, max. 380V AC
Relay variant	miniature
Coil resistance	720Ω
Operate time	10ms
Release time	10ms
Relay series	G6B
Contact resistance	30mΩ
Coil current	16.7mA
DC contacts rating @R	5A / 30V DC
AC contacts rating @R	5A / 250V AC

Extended distributor/manufacturer information (EU Regulation 2023/988)

Trade name: HESTORE Hungary Ltd
Postal address: Cziraki street 26-32, Budapest, H1163
Electronic address: https://www.hestore.hu/

Part.No: 100.435.60

Add to favorites

Quantity (pcs):

Unit price excl. VAT

1+	1 849 Ft
5+	1 614 Ft
10+	1 566 Ft
20+	1 529 Ft
50+	1 482 Ft

* The prices according to your settings are displayed without VAT, that contains your custom discount if available, without shipping costs. For modify please click

icon on top menu.

Availability	Qu.
On request
