1393204-7

Relé, elektromágneses, SPDT, 12V DC, 7A

Manufacturer partno	1393204-7
RoHS	yes
Manufacturer	TE Connectivity
Mounting	PCB
Terminal pitch	5.08mm
Operating temperature	-25...70°C
Body dimensions	21.2x16.2x14.9mm
Contact material	AgNi 90/10
Contacts configuration	SPDT
Type of relay	electromagnetic
Rated coil voltage	12V DC
Contact current max.	7A
Switched voltage	max. 400V AC, max. 60V DC
Relay variant	bistable, miniature
Coil resistance	320Ω
Coil power consumption	450mW
Relay series	UB
Switching capacity	1.75kVA
DC contacts rating @R	7A / 24V DC
AC contacts rating @R	7A / 250V AC

Extended distributor/manufacturer information (EU Regulation 2023/988)

Trade name: HESTORE Hungary Ltd
Postal address: Cziraki street 26-32, Budapest, H1163
Electronic address: https://www.hestore.hu/

Part.No: 100.408.74

Add to favorites

Quantity (pcs):

Unit price excl. VAT

1+	6 006 Ft
5+	5 600 Ft
10+	5 484 Ft
20+	5 378 Ft
50+	5 230 Ft

* The prices according to your settings are displayed without VAT, that contains your custom discount if available, without shipping costs. For modify please click

icon on top menu.

Availability	Qu.
3 workdays	> 1
