LRS-75-12

Industrial power supply, 12VDC 6A

Manufacturer partno	LRS-75-12
RoHS	yes
Manufacturer	MEAN WELL
Power	72W
Weight	300g
Output voltage	12V DC, 10.2...13.8V DC
Input voltage	85-265V AC
Output current [max.]	6A
Series	LRS-75
Mounting	mounting
Operating temperature	-30...70°C
Supply voltage	85...264V AC, 120...373V DC
Output current	6A
Type of power supply	switched-mode
Electrical connection	terminal block
Protection	overload, voltage growth, short-circuit
Number of outputs	1
Body dimensions	96 x 46.6 x 30mm, 99 x 97 x 30mm
Power supply/converter features	rated parameters obtained at full load, no load power consumption <0,3W
Efficiency	87%, 87.5%
Kind of case	240A
Tápegység fajtája	modular

Extended distributor/manufacturer information (EU Regulation 2023/988)

Trade name: HESTORE Hungary Ltd
Postal address: Cziraki street 26-32, Budapest, H1163
Electronic address: https://www.hestore.hu/

Part.No: 100.375.47

Add to favorites

Quantity (pcs):

Unit price excl. VAT

1+	5 136 Ft
5+	4 766 Ft
10+	4 664 Ft
20+	4 573 Ft
50+	4 446 Ft

* The prices according to your settings are displayed without VAT, that contains your custom discount if available, without shipping costs. For modify please click

icon on top menu.

Availability	Qu.
3 workdays	> 3000
