RM51-3011-85-1024

Relé 24V 10A/250VAC SPDT

Manufacturer partno	RM51-3011-85-1024
RoHS	yes
Manufacturer	RELPOL
Current	10A
Coil	24V DC
Contact	SPDT
Voltage	250V AC
Weight	10g
Mounting	PCB
Terminal pitch	2mm
Operating temperature	-40...85°C
Body dimensions	19.5 x 16 x 17.1mm
IP rating	IP64
Contact material	AgSnO₂
Contacts configuration	SPDT
Type of relay	electromagnetic
Rated coil voltage	24V DC
Contact current max.	10A
Switched voltage	max 30V DC, max 277V AC
Relay variant	miniature
Coil resistance	1.6kΩ
Coil voltage min.	18V DC
Coil voltage max.	31.2V DC
Operate time	15ms
Release time	10ms
Coil power consumption	360mW
Relay series	RM51
Contact resistance	100mΩ
DC contacts rating @R	10A / 30V DC
AC contacts rating @R	10A / 250V AC

Extended distributor/manufacturer information (EU Regulation 2023/988)

Trade name: HESTORE Hungary Ltd
Postal address: Cziraki street 26-32, Budapest, H1163
Electronic address: https://www.hestore.hu/

Part.No: 100.372.87

Add to favorites

Quantity (pcs):

Unit price excl. VAT

1+	706 Ft
5+	517 Ft
10+	488 Ft
20+	470 Ft
50+	451 Ft

* The prices according to your settings are displayed without VAT, that contains your custom discount if available, without shipping costs. For modify please click

icon on top menu.

Availability	Qu.
In stock	> 5
3 workdays	> 1000
