LT-24G

Name: LT-24G
Brand: RAYEX ELECTRONIC
SKU: 100.365.08
Availability: OutOfStock

Relay 24VDC 10A/120VAC

dimensions: 21.8 x 16.8 x 14.2mm

Manufacturer partno	LT-24G
RoHS	yes
Manufacturer	RAYEX ELECTRONIC, Recoy/RAYEX ELECTRONICS
Current	1A
Coil	24V DC
Contact	DPDT
Voltage	120V AC
Weight	10g
Mounting	PCB
Terminal pitch	5mm
Operating temperature	-25...60°C
Body dimensions	21.8 x 16.8 x 14.2mm
Contact material	AgCdO
Contacts configuration	SPDT
Type of relay	electromagnetic
Rated coil voltage	24V DC
Contact current max.	10A
Switched voltage	max 100V DC, max 240V AC
Relay variant	miniature
Coil resistance	1.28kΩ
Operate time	10ms
Release time	10ms
Coil power consumption	450mW
Relay series	LT
Contact resistance	100mΩ
Coil current	18.7mA
DC contacts rating @R	10A / 24V DC
AC contacts rating @R	10A / 120V AC
