QDC1S-1205S

DC/DC converter, 5V DC, SIL4

Manufacturer partno	QDC1S-1205S
RoHS	yes
Manufacturer	QLT POWER
Case	SIL4
Power	1W
Output voltage	5V DC
Input voltage	12V, 10.8...13.2V
Operating temperature	-40...85°C
Body dimensions	7 x 11.7 x 10mm
Type of integrated circuit	DC/DC converter
Protection	short circuit protection
Body dimensions	7 x 11.7 x 10mm
Efficiency	75%
Temperature coefficient	30mppm/°C, 0.03ppm/°C
Insulation voltage	1000V DC
Min. insulation resistance	1GΩ
Noise level	75Vpp
Output voltage tolerance	±10%
Type of converter	DC/DC
Switching frequency	100kHz
Input voltage tolerance	±5%

Extended distributor/manufacturer information (EU Regulation 2023/988)

Trade name: HESTORE Hungary Ltd
Postal address: Cziraki street 26-32, Budapest, H1163
Electronic address: https://www.hestore.hu/

Part.No: 100.338.30

Add to favorites

Quantity (pcs):

Unit price excl. VAT

1+	2 156 Ft
5+	1 909 Ft
10+	1 856 Ft
20+	1 813 Ft
50+	1 759 Ft
