Single 2.5V or 2.7V to 3.6V Supply

RapidS(R) Serial Interface: 66 MHz Maximum Clock Frequency

SPI Compatible Modes 0 and 3

User Configurable Page Size

256 Bytes per Page

264 Bytes per Page

Page Program Operation

Intelligent Programming Operation

2,048 Pages (256/264 Bytes/Page) Main Memory

Flexible Erase Options

Page Erase (256 Bytes)

Block Erase (2 Kbytes)

Sector Erase (64 Kbytes)

Chip Erase (4 Mbits)

Two SRAM Data Buffers (256/264 Bytes)

Allows Receiving of Data while Reprogramming the Flash Array

Continuous Read Capability through Entire Array

Ideal for Code Shadowing Applications

Low-power Dissipation

7 mA Active Read Current Typical

25 uA Standby Current Typical

5 uA Deep Power-down Typical

Hardware and Software Data Protection Features

Individual Sector

Sector Lockdown for Secure Code and Data Storage

Individual Sector

Security: 128-byte Security Register

64-byte User Programmable Space

Unique 64-byte Device Identifier

JEDEC Standard Manufacturer and Device ID Read

100,000 Program/Erase Cycles Per Page Minimum

Data Retention - 20 Years

Industrial Temperature Range

Green (Pb/Halide-free/RoHS Compliant) Packaging Options
